9000S Self-operated single-seat pressure regulating valve

Views:

1000

9000S Self-operated Pressure Regulator is a Sping-setting direct-operated universal pressure regulator. It can be use for upstream and downstream pressure control, the lowest control pressure is 3KPa and the highest control pressure is 3000KPa.

Classification:

Detailed

9000S Self-operated Pressure Regulator is a Sping-setting direct-operated universal pressure regulator. It can be use for upstream and downstream pressure control, the lowest control pressure is 3KPa and the highest control pressure is 3000KPa.

Body size:DN15~50 (1/2”~2”)

Body rating:PN16~PN100(ANSI150#~600#)

Body Material: WCB、CF8、CF8M、CF3、CF3M

Operating temperature: -48~+300℃

    • Straight ball
    • valves Ball
    • valves Flow paths
