3001K Soft seal straight through ball valve

Views:

1000

This 3001K series provides ball vavles with a special inner valve which can be fully opened or closed by simply causing the stem to make a 1/4 turn. The offtake from a ball valve, when totally opened, has the same bore as the pipeline and its fliud resistance is negligible. For this reason, this automatic valve is best suited to on-off service, controlling various types of liquid, gas and slurry.

Classification:

Detailed



This 3001K series provides ball vavles with a special inner valve which can be fully opened or closed by simply causing the stem to make a 1/4 turn. The offtake from a ball valve, when totally opened, has the same bore as the pipeline and its fliud resistance is negligible. For this reason, this automatic valve is best suited to on-off service, controlling various types of liquid, gas and slurry.

Body size: DN15~300(1/2”~12”)
Body ratings: PN16~PN100(ANSI150#~600#)
Body Material: WCB、CF8、CF8M、CF3、CF3M….
Operating temperature: -20~+200℃

    • Straight ball
    • valves Ball
    • valves Flow paths
