9111G Commander-operated self-operated micro-pressure valves

Views:

1000

9111G pressure regulating valve is a micro-pressure regulating valve for pilot type and extensively applied for the micro-pressure control of different gas and micro-pressure nitrogen blanketing. It can regulate the middle-pressure gas to reduce and stabilize the pressure to minimal pressure in a regulation. The minimal control pressure is 0.15KPa.

Classification:

Detailed

9111G pressure regulating valve is a micro-pressure regulating valve for pilot type and extensively applied for the micro-pressure control of different gas and micro-pressure nitrogen blanketing. It can regulate the middle-pressure gas to reduce and stabilize the pressure to minimal pressure in a regulation. The minimal control pressure is 0.15KPa.

The maximum control pressure is 12KPa.

Body size:DN15~100 (1/2”~4”)

Body rating:PN16~PN100(ANSI150#~600#)

Body Material: WCB、CF8、CF8M、CF3、CF3M

Operating temperature: -48~+120℃
