9000C Self-acting Cage Pressure Regulating Valve

Views:

1000

9000C Self-operated Pressure Regulator is a Spring-setting direct-operated universal pressure regulator. It can be use for upstream and downstream pressure control.

Classification:

Detailed



9000C Self-operated Pressure Regulator is a Spring-setting direct-operated universal pressure regulator. It can be use for upstream and downstream pressure control.
The lowest control pressure is 3KPa and the highest control pressure is 3000KPa.

Body size: DN40~200 (1-1/2”~8”)

Body rating: PN16~PN100(ANSI150#~600#)

Body Material: WCB、CF8、CF8M、CF3、CF3M

Operating temperature: -48~+300℃
