5003C Sleeve-guided control valve

Views:

1000

The Series 5003C Cage Guided Control Valves, The valve structure is compact, which is characterized by the S-shaped fluid channel pressure loss, flow capacity, adjustable ratio, high accuracy of flow characteristics, due to the addition of a balance seal ring in the sleeve structure, the valve dynamic stability is higher, suitable for harsh working conditions of high performance regulator. Due to a structure that equalizes the fluid pressure acting on the spool, stable regulation is achieved with only a small operating force.

Classification:

Detailed



The Series 5003C Cage Guided Control Valves, The valve structure is compact, which is characterized by the S-shaped fluid channel pressure loss, flow capacity, adjustable ratio, high accuracy of flow characteristics, due to the addition of a balance seal ring in the sleeve structure, the valve dynamic stability is higher, suitable for harsh working conditions of high performance regulator. Due to a structure that equalizes the fluid pressure acting on the spool, stable regulation is achieved with only a small operating force.

Body size: DN40~450(1-1/2”~18”)

Body rating: PN16~PN100(ANSI150#~600#)

Body Material: LCB、WCB、WC5、WC6、WC9、CF8、CF8M、CF3、CF3M

Operating temperature: -196~+566℃
